SPECIFICATIONS
Overview |
|
|---|---|
| Engine | Yanmar Customized Engine |
| Weight | 3860 kg |
| Rated Power | 20.3/2200 kW/rpm |
| Bucket Digging Force | – |
| Hydraulic Pump Flow | 88 L/pm |
| Warranty | 5 Year/5000 hr |
Engine |
|
| Engine Model | Yanmar 3TNV88F-ESSY |
| Rated Power | 20.3/2200 kW/rpm |
| Max. Torque | – |
| Displacement | 1.6 L |
| Emission Standard | Tier 4f |
Operation Range |
|
| Weight | 3860 kg |
| Max. Digging Height | 4855 mm |
| Max. Digging Force – Arm | 18.2 kN |
| Max. Digging Depth | 3105 mm |
| Max. Vertical Digging Depth | 2700 mm |
| Max. Excavating Distance | 5465 mm |
| Min. Swing Radius | 2475 mm |
| Height at Min. Swing Radius | 3685 mm |
| Max. Ground Clearance of Blade Up | – |
| Max. Depth of Blade Down | – |
Dimensions |
|
| Transport Length | 4915 mm |
| Transport Width | 1720 mm |
| Transport Height | 2515 mm |
| Upper Width | 1550 mm |
| Blade Height | – |
| Tail Swing Radius | 1670 mm |
| Min. Ground Clearance | 295 mm |
Undercarriage/Working Device |
|
| Std. Track Shoe Width | – |
| Bucket Capacity | – |
| Track Gauge | 1420 mm |
| Roller Gauge | 1670 mm |
| Boom Length | – |
| Arm Length | – |
Performance |
|
| Travel Speed | 4.4/2.4 km/h |
| Swing Speed | 9 rpm |
| Gradeability | 58% |
| Std. Operating Weight | 32 kPa |
| Bucket Digging Force | – |
| Arm Digging Force | 18.2 kN |
| Fuel Tank Capacity | 40 L |
| Hydraulic Tank Capacity | 40 L |
